Pilous Arg 260 Plus F With Work Light (Single Phase)
Innovated version of the well-known ARG 250 model series that has been produced for 25 years, with a brand new, uniquely designed saw band arm. Increased maximum diameter of the split material from 250 mm to 260 mm. The latest concept of the arm casting with cavities is fitted with running wheels with an increased diameter. The larger diameter of the wheels ensures less bending stress of the saw band. All this ensures an outstanding rigidity of the whole system, long service life of saw bands and maximum cut precision. The hollow parts of the arm contains all wiring and coolant lines, which protects them from damage. The new arm concept also greatly simplifies saw band replacement or cleaning of the inside of the arm - you just open the hinged cover and it stays in the upper position. Apart from creating an entirely new design of the arm, we also made many technical adjustments and changes improving the quality, user comfort and service life of the machine. In addition, the arm uplift now also has a height-adjustable lever for ergonomic operation. As an accessory, you can use a saw band cleaning brush, synchronously driven from the drive wheel.
Universal robust band saw is appraised for general use in continuous uninterrupted production plants and in work-shops (work on locks, maintenance) as well. Industrial band 27 x 0.9 mm is manufactured in many versions and allows for cutting of wide range of materials, including stainless steel or tool steel.
The band saw arm uplift is manual; the feed into cut is carried out by the weight of the arm, with the possibility of continuous regulation by the oil damper butterfly valve. When the cut is finished the band saw drive automatically switches off. To facilitate easy arm uplift the machine is equipped with adjustable tension springs that allow for setting of optimum force required for the arm uplift according to characteristics of the material to be cut. Vice system contributes to versatility of use by providing bilateral continuous setting of the cutting angle within the ranges 60° to the right and 45° to the left. Large base and massive arm turning system with large loading surfaces ensure exceptional stability of the machine even when cutting heavy workpieces.
Robust machine framework composes of castings from grey cast iron and therefore ensures vibration absorption.
Modern concept of the band saw arm allows for large cutting ranges in upright and angular cuts.
Simple locking and adjusting of the desired cutting angle on the angle scale with stops fixed at 60° to the right and 45° to the left.
The turntable rotates along with the saw band. Thanks to that the saw band does not cut into the loading surface of the vice.
Massive quick-clamping vice ensures easy and reliable material clamping.
Large diameter running wheels and precise three-side hardmetal guiding ensure long service life of the band and cutting accuracy.
Overdesign of running wheel bearings, tensioning wheel system and all rotary parts ensures long service life of the machine.
Noiseless and maintenance-free band drive is provided by an industrial electric motor with worm gearbox.
Three-phase two-speed motor (400 V) allows you to select the speed of 35 or 75 m/min. according to characteristics of the material to be cut.
The machine is connected to a complete cooling system with a high-performance pump and possibility of regulating the
flow on both guiding heads independently. Coolant tank with a pump is placed in the base of the machine.
Easy control by ergonomically placed controls (electrical and hydraulics) on the base of the machine.
The machine is equipped with a hinged stop with a 500mm scale. Hinged system prevents the workpiece from jamming during cutting.
Main motor 400 V, 50 Hz, 0,9/1,4 kW
Pump motor 400 V, 50 Hz, 0,05 kW
Saw blade speed 35/70 m/min.
Working height of vice 910 mm
Coolant tank cca 15 l
Machine dimensions (min.) 1620 x 950 x 1420 mm
Machine dimensions (max.) 1860 x 1680 x 1980 mm
Machine weight 475 kg
